IR2304STRPBF Real Image IR2304STRPBF real image231
Same model may have multiple batches, images only for reference.
IR2304STRPBF Real Image IR2304STRPBF real image231
IR2304STRPBF Real Image IR2304STRPBF real image231
Same model may have multiple batches, images only for reference.

IR2304STRPBF

Part No IR2304STRPBF
Manufacturer Infineon Technologies
Catalog PMIC - Gate Drivers
Description Driver 600V 0.13A 2-OUT High and Low Side Half Brdg Non-Inv 8-Pin SOIC N T/R / IC DVR HALF BRIDGE 8-SOIC
Datasheet
IR2304STRPBF Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Integrated Circuits
Manufacturer Infineon Technologies
Packaging Reel - TR
Status Active
Driven Configuration Half-Bridge
Channel Type Independent
Number of Drivers 2
Gate Type IGBT, N-Channel MOSFET
Supply Voltage - Operating 10 V to 20 V
Logic Voltage - VIL, VIH 0.8V, 2.3V
Current - Peak Output (Source, Sink) 60mA, 130mA
Input Type Non-Inverting
High Side Voltage - Max (Bootstrap) 600V
Rise and Fall Time 200ns, 100ns
Temperature Range - Operating -40°C to 150°C (TJ)
Mounting SMD (SMT)
Case / Package 8-SOIC
Win Source Part Number 069180-IR2304STRPBF
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Balance
Family Name IR2304
Introduction Date August 04, 2003
ECCN EAR99
Country of Origin Thailand
Estimated EOL Date 2025
Ultra Librarian 3D Model Ultra Librarian IR2304STRPBF CAD Model

Description

The Infineon Technologies IR2304STRPBF is a half-bridge gate driver IC with two independent channels for driving IGBTs and N-channel MOSFETs.

  • Input Type: Non-inverting
  • Logic Voltage Range: 0.8V to 2.3V
  • Peak Output Current (Source): 60mA
  • Peak Output Current (Sink): 130mA
  • Bootstrap High Side Voltage Max: 600V
  • Packaging: 8-SOIC
  • Operating Temperature: -40°C to 150°C
  • Supply and Demand Status: balanced
  • Estimated EOL Date: 2025
