IR5001STR Infineon Technologies IR5001STR label picture IR5001STR label picture 2
Same model may have multiple batches, images only for reference.
IR5001STR Infineon Technologies IR5001STR label picture IR5001STR label picture 2
IR5001STR Infineon Technologies IR5001STR label picture IR5001STR label picture 2
Same model may have multiple batches, images only for reference.

IR5001STR

Part No IR5001STR
Manufacturer Infineon Technologies
Catalog PMIC - OR Controllers, Ideal Diodes
Description OR Controller N-Channel Single 8-Pin SOIC T/R / IC OR CTRLR N+1 8SOIC
Datasheet
IR5001STR Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Integrated Circuits
Manufacturer Infineon Technologies
Packaging Cut Reel
Status Obsolete(EOL)
Type N+1 ORing Controller
Polarity N-Channel
Delay Time - ON 27μs
Delay Time - OFF 130ns
Operating Supply Current 500μA
Supply Voltage - Operating 36 V to 75 V
Applications -48V Dist Power Systems
Temperature Range - Operating 0°C to 85°C
Mounting SMD (SMT)
Case / Package 8-SOIC
Win Source Part Number 121613-IR5001STR
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Balance
Quantity per package 1
Family Name IR5001S
Introduction Date December 16, 2005
ECCN EAR99
Halogen Free Compliant
Estimated EOL Date Obsolete / End of life
Ultra Librarian 3D Model Ultra Librarian IR5001STR CAD Model

Description

The Infineon Technologies IR5001STR is an N+1 ORing controller with a delay time of 27μs (ON) and 130ns (OFF). The product is designed for -48V Dist Power Systems and is mounted using surface mount technology (SMT).

  • Delay Time (ON): 27μs
  • Delay Time (OFF): 130ns
  • Application: -48V Dist Power Systems
  • Mounting: Surface Mount Technology (SMT)
  • Polarity: N-Channel
  • Packaging: Cut Reel
  • Supply and demand status: balanced
  • Regulation Compliance: halogen-free standards
