IRF6201PBF Real Image IRF6201PBF Real Image
Same model may have multiple batches, images only for reference.
IRF6201PBF Real Image IRF6201PBF Real Image
IRF6201PBF Real Image IRF6201PBF Real Image
Same model may have multiple batches, images only for reference.

IRF6201PBF

Part No IRF6201PBF
Manufacturer Infineon Technologies
Catalog FETs - Single
Description HEXFETPower MOSFET | MOSFET N-CH 20V 27A 8-SO
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Discrete Semiconductor Products
Manufacturer Infineon Technologies
Packaging Tube
Transistor Polarity N-Channel
Technology MOSFET
Vds - Drain-Source Breakdown Voltage 20V
Id - Continuous Drain Current 27A
Drive Voltage (Max Rds On, Min Rds On) 2.5V, 4.5V
Rds On (Maximum) at Id, Vgs 2.45mOhm at 27A, 4.5V
Gate Source Voltage(th) (Maximum) at Id 1.1V at 100μA
Gate Charge (Qg) (Maximum) at Vgs 195nC at 4.5V
Gate Source Voltage (Maximum) ±12V
Input Capacitance (Ciss) (Maximum) at Vds 8555pF at 16V
Power Dissipation (Maximum) 2.5W
Temperature Range - Operating -55°C ~ 150°C
Mounting Style SMD
Supplier Device Package 8-SO
Manufacturer Package 8-SOIC
Manufacturer Pack Quantity 3,800
MSL Level 1 (Unlimited)
Win Source Part Number 1187083-IRF6201PBF
Manufacturer Homepage www.irf.com
Popularity Medium
Supply and Demand Status Limited
Ultra Librarian 3D Model Ultra Librarian IRF6201PBF CAD Model

Description

The Infineon Technologies IRF6201PBF is a N-Channel MOSFET transistor used in discrete semiconductor products.

  • Drain-Source Breakdown Voltage: 20V
  • Continuous Drain Current: 27A
  • Maximum Rds On @ Id, Vgs: 2.45mOhm @ 27A, 4.5V
  • Gate-Source Voltage (th) (maximum) @ Id: 1.1V @ 100μA
  • Gate Charge (Qg) (maximum) @ Vgs: 195nC @ 4.5V
  • Input Capacitance (Ciss) (maximum) @ Vds: 8555pF @ 16V
  • Power Dissipation: 2.5W (maximum)
  • Packaging: Tube
  • Mount Style: 8-SO
  • Drive Voltage (max Rds On, min Rds On): 2.5V, 4.5V
  • Gate-Source Voltage (maximum): ±12V
  • Temperature Range: -55°C to 150°C
  • Supply and Demand: Limited
  • Manufacturer Pack Quantity: 3,800
