Same model may have multiple batches, images only for reference.

IRF7452TRPBF

Name: IRF7452TRPBF
Brand: Infineon Technologies
SKU: 159954
Availability: InStock
Rating: 4.85 (5 reviews)

Get a Quote

Part No	IRF7452TRPBF
Manufacturer	Infineon Technologies
Catalog	Transistors - FETs, MOSFETs - RF
Description	MOSFET N-CH 100V 4.5A 8-SOIC / Trans MOSFET N-CH 100V 4.5A 8-Pin SOIC T/R
Sample
Rohs State
ECAD Module
	Add to BOM List New List Existing List This product has been added to your list. List name
Need Help

Products specifications Report Issue?

Categories	Discrete Semiconductor Products
Manufacturer	Infineon Technologies
Packaging	Reel - TR
Status	Active
Polarity	N-Channel
Technology	MOSFET
Drain-Source Breakdown Voltage	100V
Continuous Drain Current at 25°C	4.5A (Ta)
Drive Voltage (Max Rds On, Min Rds On)	10V
Gate-Source Threshold Voltage	5.5V @ 250μA
Max Gate Charge	50nC @ 10V
Max Input Capacitance	930pF @ 25V
Maximum Gate-Source Voltage	±30V
Power Dissipation (Max)	2.5W (Ta)
Maximum Rds On at Id,Vgs	60 mOhm @ 2.7A, 10V
Temperature Range - Operating	-55°C to 150°C (TJ)
Mounting	SMD (SMT)
Case / Package	8-SO
Dimension	8-SOIC (0.154", 3.90mm Width)
Win Source Part Number	001863-IRF7452TRPBF
Is this a common-used part?	Yes
Popularity	High
Supply and Demand Status	Balance
Family Name	IRF7452
Introduction Date	October 25, 2000
ECCN	EAR99
Country of Origin	Austria, China, Malaysia, Mexico, Philippines, Taiwan, Thailand
Halogen Free	Compliant
Estimated EOL Date	2021
Ultra Librarian 3D Model	Ultra Librarian IRF7452TRPBF CAD Model

Description

The Infineon Technologies 001863-IRF7452TRPBF is a high-performance N-channel MOSFET that is commonly used in various electronic applications.

Drain-Source Breakdown Voltage: 100V
Continuous Drain Current: 4.5A (Ta) @ 25°C
Maximum Rds On: 60 mOhm @ 2.7A, 10V
Gate-Source Threshold Voltage: 5.5V @ 250μA
Maximum Gate Charge: 50nC @ 10V
Maximum Input Capacitance: 930pF @ 25V
Package: 8-SO
Mountable using: SMD (SMT) technology
Quantity per Package: 1
