IRFHS9301TR2PBF

Name: IRFHS9301TR2PBF
Brand: Infineon Technologies
SKU: 462099
Availability: InStock
Rating: 4.93 (5 reviews)

Get a Quote

Part No	IRFHS9301TR2PBF
Manufacturer	Infineon Technologies
Catalog	Transistors - FETs, MOSFETs - RF
Description	MOSFET P-CH 30V 6A PQFN
Datasheet	IRFHS9301TR2PBF Datasheet
Sample
Rohs State
ECAD Module
	Add to BOM List New List Existing List This product has been added to your list. List name
Need Help

Products specifications Report Issue?

Categories	Discrete Semiconductor Products
Manufacturer	Infineon Technologies
Packaging	Cut Reel
Status	Obsolete(EOL)
Polarity	P-Channel
Technology	MOSFET
Drain-Source Breakdown Voltage	30V
Continuous Drain Current at 25°C	6A (Ta), 13A (Tc)
Drive Voltage (Max Rds On, Min Rds On)	4.5V, 10V
Gate-Source Threshold Voltage	2.4V @ 25μA
Max Gate Charge	13nC @ 10V
Max Input Capacitance	580pF @ 25V
Maximum Gate-Source Voltage	±20V
Power Dissipation (Max)	2.1W (Ta)
Maximum Rds On at Id,Vgs	37 mOhm @ 7.8A, 10V
Temperature Range - Operating	-55°C to 150°C (TJ)
Mounting	SMD (SMT)
Case / Package	6-PQFN (2x2)
Dimension	6-PowerVDFN
Win Source Part Number	1046920-IRFHS9301TR2PBF
Popularity	Medium
Supply and Demand Status	Balance
Ultra Librarian 3D Model	Ultra Librarian IRFHS9301TR2PBF CAD Model

Alternative Products

Description

The Infineon Technologies IRFHS9301TR2PBF is a P-channel MOSFET with a drain-source breakdown voltage of 30V.

Maximum Power Dissipation: 2.1W (Ta)
Continuous Drain Current: 6A (Ta), 13A (Tc) @ 25°C
Gate-Source Threshold Voltage: 2.4V @ 25μA
Maximum Gate Charge: 13nC @ 10V
Maximum Input Capacitance: 580pF @ 25V
Maximum Rds On: 37 mOhm @ 7.8A, 10V
Package: 6-PQFN (2x2)
Dimension: 6-PowerVDFN
Drive Voltage: 4.5V, 10V
Temperature Range: -55°C to 150°C (TJ)
Lifecycle Status: Obsolete (EOL)
Popularity: Medium
