IRFP4368PBF

Part No IRFP4368PBF
Manufacturer Infineon Technologies
Catalog Transistors - FETs, MOSFETs - RF
Description MOSFET N-CH 75V 195A TO-247AC
Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Discrete Semiconductor Products
Manufacturer Infineon Technologies
Packaging Tube/Rail
Status Active
Polarity N-Channel
Technology MOSFET
Drain-Source Breakdown Voltage 75V
Continuous Drain Current at 25°C 195A (Tc)
Drive Voltage (Max Rds On, Min Rds On) 10V
Gate-Source Threshold Voltage 4V @ 250μA
Max Gate Charge 570nC @ 10V
Max Input Capacitance 19230pF @ 50V
Maximum Gate-Source Voltage ±20V
Power Dissipation (Max) 520W (Tc)
Maximum Rds On at Id,Vgs 1.85 mOhm @ 195A, 10V
Temperature Range - Operating -55°C to 175°C (TJ)
Mounting Through Hole
Case / Package TO-247AC
Dimension TO-247-3
Win Source Part Number 087841-IRFP4368PBF
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Balance
Ultra Librarian 3D Model Ultra Librarian IRFP4368PBF CAD Model

Description

IRFP4368PBF from Infineon Technologies is a power MOSFET used in designs that require efficient switching and solid current handling in demanding electronic systems. Although the provided category lists RF MOSFETs, engineers should confirm the exact device classification and electrical characteristics in the official manufacturer datasheet before design-in. This component is typically evaluated for power conversion, motor control, switching stages, and other high-performance transistor applications where thermal behavior, conduction losses, and package reliability matter. Infineon is widely recognized for robust semiconductor solutions, making this part relevant for industrial, automotive-adjacent, and embedded power designs where sourcing confidence is important. Lifecycle status information is not available from the input, so teams should verify whether the part is active, not recommended for new designs, or approaching end-of-life through official channels. RoHS compliance status is also information not available here; procurement and compliance teams should request current manufacturer documentation before approval.
