IRFR7446TRPBF Real Image IRFR7446TRPBF Real Image
Same model may have multiple batches, images only for reference.
IRFR7446TRPBF Real Image IRFR7446TRPBF Real Image
IRFR7446TRPBF Real Image IRFR7446TRPBF Real Image
Same model may have multiple batches, images only for reference.

IRFR7446TRPBF

Part No IRFR7446TRPBF
Manufacturer Infineon Technologies
Catalog Transistors - FETs, MOSFETs - RF
Description MOSFET N-CH 40V 56A DPAK
Datasheet
IRFR7446TRPBF Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Discrete Semiconductor Products
Manufacturer Infineon Technologies
Packaging Reel - TR
Status Active
Polarity N-Channel
Technology MOSFET
Drain-Source Breakdown Voltage 40V
Continuous Drain Current at 25°C 56A (Tc)
Drive Voltage (Max Rds On, Min Rds On) 6V, 10V
Gate-Source Threshold Voltage 3.9V @ 100μA
Max Gate Charge 130nC @ 10V
Max Input Capacitance 3150pF @ 25V
Maximum Gate-Source Voltage ±20V
Power Dissipation (Max) 98W (Tc)
Maximum Rds On at Id,Vgs 3.9 mOhm @ 56A, 10V
Temperature Range - Operating -55°C to 175°C (TJ)
Mounting SMD (SMT)
Case / Package D-Pak
Dimension TO-252-3, DPak (2 Leads + Tab), SC-63
Win Source Part Number 017694-IRFR7446TRPBF
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Balance
Ultra Librarian 3D Model Ultra Librarian IRFR7446TRPBF CAD Model

Description

The supply and demand status for this component is balance.

  • Manufacturer: Infineon Technologies
  • Win Source Part Number: 017694
  • Component: MOSFET
  • Power Dissipation: 98W (Tc)
  • Polarity: N-Channel
  • Maximum Rds On at Id,Vgs: 3.9 mOhm @ 56A, 10V
