IRGP4062DPBF Real Image IRGP4062DPBF real image378 IRGP4062DPBF Real Image
Same model may have multiple batches, images only for reference.
IRGP4062DPBF Real Image IRGP4062DPBF real image378 IRGP4062DPBF Real Image
IRGP4062DPBF Real Image IRGP4062DPBF real image378 IRGP4062DPBF Real Image
Same model may have multiple batches, images only for reference.

IRGP4062DPBF

Part No IRGP4062DPBF
Manufacturer Infineon Technologies
Catalog IGBTs - Single
Description IGBT 600V 48A 250W TO247AC
Datasheet
IRGP4062DPBF Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Discrete Semiconductor Products
Manufacturer Infineon Technologies
Packaging Bulk
Status Not For New Designs
IGBT Type Trench
VCEO Maximum Collector-Emitter Breakdown Voltage 600V
Maximum Current Collector 48A
Pulsed Collector Current 72A
Collector-emitter saturation voltage(Max) 1.95V @ 15V, 24A
Maximum Power Dissipation 250W
Total Switching Energy(Ets) 115μJ (on), 600μJ (off)
Input Type Standard
Gate Charge 50nC
Turn-on and Turn-off delay time 41ns/104ns
Testing Conditions 400V, 24A, 10 Ohm, 15V
Reverse Recovery Time (trr) 89ns
Temperature Range - Operating -55°C to 175°C (TJ)
Mounting Through Hole
Case / Package TO-247AC
Win Source Part Number 069675-IRGP4062DPBF
Family Name IRGP4062D
Introduction Date February 24, 2006
ECCN EAR99
Country of Origin Mexico
Halogen Free Not Compliant
Estimated EOL Date 2024
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Balance
Ultra Librarian 3D Model Ultra Librarian IRGP4062DPBF CAD Model

Description

The Infineon Technologies IRGP4062DPBF is a widely used electronic component that is designed for use in discrete semiconductor products. The Win Source Part Number for this component is 069675-IRGP4062DPBF.

  • Halogen-Free: It is not compliant with halogen-free standards.
