IRL80HS120

Name: IRL80HS120
Brand: Infineon Technologies
SKU: 967830
Availability: InStock
Rating: 4.93 (5 reviews)

Get a Quote

This model is a standard, industry-grade component frequently used in electronic manufacturing.

Part No	IRL80HS120
Manufacturer	Infineon Technologies
Catalog	Transistors - FETs, MOSFETs - RF
Description	MOSFET N-CH 80V 12.5A 6PQFN / N-Channel 80 V 12.5A (Tc) 11.5W (Tc) Surface Mount 6-PQFN (2x2)
Datasheet	IRL80HS120 Datasheet
Sample
Rohs State
ECAD Module
	Add to BOM List New List Existing List This product has been added to your list. List name
Need Help

Products specifications Report Issue?

Category	Discrete Semiconductor Products>Transistors - FETs, MOSFETs - Single
Mfr	Infineon Technologies
Package	Tape & Reel
FET Type	N-Channel
Technology	MOSFET (Metal Oxide)
Drain to Source Voltage (Vdss)	80 V
Current - Continuous Drain (Id) @ 25°C	12.5A (Tc)
Drive Voltage (Max Rds On, Min Rds On)	4.5V, 10V
Rds On (Max) @ Id, Vgs	32mOhm @ 7.5A, 10V
Vgs(th) (Max) @ Id	2V @ 10µA
Gate Charge (Qg) (Max) @ Vgs	7 nC @ 4.5 V
Vgs (Max)	±20V
Input Capacitance (Ciss) (Max) @ Vds	540 pF @ 25 V
Power Dissipation (Max)	11.5W (Tc)
Temperature Range - Operating	-55°C ~ 175°C (TJ)
Mounting	SMD (SMT)
Supplier Device Package	6-PQFN (2x2)
Package / Case	6-VDFN Exposed Pad
Base Product Number	IRL80HS120
MSL Level	1 (Unlimited)
REACH Status	REACH Unaffected
ECCN	EAR99
HTSUS	8541.29.0095
Other Names	SP001592838,IRL80HS120TR,IRL80HS120CT,IRL80HS120DKR
Standard Package	4,000
Win Source Part Number	967830-IRL80HS120
Ultra Librarian 3D Model	Ultra Librarian IRL80HS120 CAD Model

Alternative Products

Description

The Infineon Technologies 967830-IRL80HS120 is an N-Channel MOSFET component in the Discrete Semiconductor Products category. It has a maximum drain to source voltage of 80V and a continuous drain current of 12.5A at 25°C.
