SPB11N60C3 Real Image SPB11N60C3 real image6437
Same model may have multiple batches, images only for reference.
SPB11N60C3 Real Image SPB11N60C3 real image6437
SPB11N60C3 Real Image SPB11N60C3 real image6437
Same model may have multiple batches, images only for reference.

SPB11N60C3

Part No SPB11N60C3
Manufacturer Infineon Technologies
Catalog Transistors - FETs, MOSFETs - RF
Description MOSFET N-CH 650V 11A D2PAK
Datasheet
SPB11N60C3 Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Discrete Semiconductor Products
Manufacturer Infineon Technologies
Packaging Reel - TR
Status Active
Polarity N-Channel
Technology MOSFET
Drain-Source Breakdown Voltage 650V
Continuous Drain Current at 25°C 11A (Tc)
Drive Voltage (Max Rds On, Min Rds On) 10V
Gate-Source Threshold Voltage 3.9V @ 500μA
Max Gate Charge 60nC @ 10V
Max Input Capacitance 1200pF @ 25V
Maximum Gate-Source Voltage ±20V
Power Dissipation (Max) 125W (Tc)
Maximum Rds On at Id,Vgs 380 mOhm @ 7A, 10V
Temperature Range - Operating -55°C to 150°C (TJ)
Mounting SMD (SMT)
Case / Package PG-TO263-3-2
Dimension TO-263-3, D2Pak (2 Leads + Tab), TO-263AB
Win Source Part Number 005203-SPB11N60C3
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Limited
Ultra Librarian 3D Model Ultra Librarian SPB11N60C3 CAD Model

Description

The Infineon Technologies SPB11N60C3 is a high-performance N-channel MOSFET designed for use in discrete semiconductor products.

  • Drain-Source Breakdown Voltage: 650V
  • Continuous Drain Current: 11A @ 25°C
  • Package: PG-TO263-3-2
  • Mounting: SMD (SMT)
  • Power Dissipation: 125W (Tc)
  • Maximum Rds On: 380 mOhm @ 7A, 10V
  • Gate-Source Threshold Voltage: 3.9V @ 500μA
  • Maximum Gate Charge: 60nC @ 10V
  • Maximum Input Capacitance: 1200pF @ 25V
  • Maximum Gate-Source Voltage: ±20V
  • Supply and demand status: limited
