The ICS840021AGILF is a low skew, high performance 1-to-2 LVCMOS/LVTTL Fanout Buffer. The device is designed for clock distribution applications where minimal skew and low additive jitter are critical. It accepts one clock input and provides two identical outputs, making it suitable for driving multiple loads in a system.

Applications:

• Clock distribution
• Networking equipment
• Servers
• Data centers
• Telecommunications equipment
• High-performance computing

Features:

• 1-to-2 LVCMOS/LVTTL fanout buffer
• Low skew (typically less than 50ps)
• Low additive jitter
• Operating frequency up to 200 MHz
• Output enable pin for power management
• 3.3V power supply operation
• Available in a small package (e.g., TSSOP)

Benefits:

• Improved clock signal integrity
• Reduced timing uncertainty
• Enhanced system performance
• Simplified clock distribution network
• Lower power consumption
• Compact footprint

Additional Details:

The ICS840021AGILF features a typical output skew of less than 50ps, ensuring that the clock signals arrive at their destinations with minimal timing difference. The low additive jitter helps to maintain the integrity of the clock signal, reducing the likelihood of errors in the system. The device operates from a 3.3V power supply and is available in a small surface-mount package, such as TSSOP. The output enable pin allows the outputs to be disabled for power management purposes. Detailed electrical specifications, including input and output voltage levels, timing parameters, and power consumption, can be found in the device datasheet. This part is commonly used in applications where precise clock timing is essential, such as high-speed data transmission and signal processing.
