The 30CTH02-1PBF is a dual common cathode Schottky Rectifier module from International Rectifier (now Infineon Technologies). It is designed for high-frequency switching power supplies and other applications requiring efficient rectification.

Applications:

• Switching Power Supplies
• Freewheeling diodes
• Polarity protection
• High-frequency inverters
• DC-DC converters

Features:

• Low forward voltage drop: Reduces power loss and improves efficiency.
• High surge current capability: Provides protection against transient voltage spikes.
• High-frequency operation: Suitable for use in high-frequency circuits.
• RoHS Compliant: Complies with environmental regulations.
• Avalanche energy rated: Ensures robust performance and reliability.

Benefits:

• Improved Efficiency: Low forward voltage drop minimizes power loss.
• Robust Protection: High surge current capability protects against transient voltage spikes.
• Reliable Performance: Avalanche energy rating ensures robust operation under stress conditions.
• Environmentally Friendly: RoHS compliance ensures environmental safety.
• Simplified Circuit Design: Dual common cathode configuration simplifies circuit layout.

Additional Details:

The 30CTH02-1PBF has a maximum repetitive peak reverse voltage of 20V. The forward current is 2x15A (30A total). It is packaged in a TO-220AB package. The low forward voltage drop contributes to the overall efficiency of the power supply or circuit in which it is used. The high surge current capability ensures it can withstand transient voltage conditions, preventing damage to the rectifier and other components in the circuit.
