The IRF2907ZS-7PTRRPBF is an Automotive Grade N-Channel MOSFET from International Rectifier, now part of Infineon Technologies. This power MOSFET is designed for high-current, high-performance automotive applications. Its key features include extremely low on-resistance, fast switching speed, and robust design for harsh automotive environments.

Applications:

• Automotive motor control
• Automotive DC-DC converters
• Automotive power distribution
• Automotive solenoid drivers
• Heavy Load Switching

Features:

• N-Channel MOSFET
• Automotive Grade (AEC-Q101 Qualified)
• Extremely Low On-Resistance (RDS(on))
• Fast Switching Speed
• Avalanche Rated
• 175°C Operating Temperature
• RoHS Compliant

Benefits:

• Improved Efficiency: Very low RDS(on) minimizes power losses in high current applications.
• Reduced Switching Losses: Fast switching characteristics enable higher frequency operation.
• Enhanced Reliability: Automotive grade qualification ensures robust performance in harsh conditions.
• Simplified Thermal Management: Low RDS(on) reduces heat generation.
• Compliance with Automotive Standards: AEC-Q101 qualified for automotive applications.

Additional Details:

The IRF2907ZS-7PTRRPBF has a drain-source voltage (Vds) of 75V, a continuous drain current (Id) of 120A (limited by package), and a pulsed drain current (Idm) of 470A. The typical on-resistance (RDS(on)) is 4.5 mOhms at Vgs = 10V. The gate charge (Qg) is typically 66 nC. The device is designed for automotive applications, meaning it has been qualified to AEC-Q101 standards for reliability and performance in automotive environments. The low RDS(on) makes it ideal for applications where minimizing power loss is critical. The MOSFET is packaged in a D2PAK-7L package to ensure good thermal dissipation.
