ISL3178EIBZ-T Real Image ISL3178EIBZ-T real image ISL3178EIBZ-T label picture ISL3178EIBZ-T label picture 2 ISL3178EIBZ-T Real Image
Same model may have multiple batches, images only for reference.
ISL3178EIBZ-T Real Image ISL3178EIBZ-T real image ISL3178EIBZ-T label picture ISL3178EIBZ-T label picture 2 ISL3178EIBZ-T Real Image
ISL3178EIBZ-T Real Image ISL3178EIBZ-T real image ISL3178EIBZ-T label picture ISL3178EIBZ-T label picture 2 ISL3178EIBZ-T Real Image
Same model may have multiple batches, images only for reference.

ISL3178EIBZ-T

Part No ISL3178EIBZ-T
Manufacturer Intersil
Catalog Interface - Drivers, Receivers, Transceivers
Description IC TXRX RS485/422 ESD 8SOIC
Datasheet
ISL3178EIBZ-T Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Integrated Circuits
Manufacturer Intersil
Packaging Reel - TR
Status Active
Type Transceiver
Protocol RS422, RS485
Number of Drivers/Receivers 1/1
Duplex Half
Receiver Hysteresis 15mV
Data Rate 20Mbps
Supply Voltage - Operating 3 V to 3.6 V
Temperature Range - Operating -40°C to 85°C
Mounting SMD (SMT)
Case / Package 8-SOIC
Win Source Part Number 091664-ISL3178EIBZ-T
Family Name ISL3178E
Introduction Date March 27, 2003
ECCN EAR99
Country of Origin Taiwan
Estimated EOL Date 2023
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Balance
Quantity per package 2,500
Ultra Librarian 3D Model Ultra Librarian ISL3178EIBZ-T CAD Model

Description

The ISL3178EIBZ-T is a half-duplex RS-485/RS-422 transceiver manufactured by Intersil.

  • Data Rate: 20Mbps
  • Receiver Hysteresis: 15mV
  • Case/Package: 8-SOIC
  • Temperature Range: -40°C to 85°C
  • Supply Voltage: 3V to 3.6V
  • Application: Industrial automation, HVAC control, and security systems
