The LRC-LRF2512-01-R020-F is a precision, thick film, low resistance chip resistor manufactured by IRC, a TT electronics Company. This resistor is designed for current sensing applications and other circuits requiring accurate and stable low resistance values.

Applications

• Current sensing in power supplies
• Current sensing in motor control circuits
• Current sensing in battery management systems
• High precision voltage dividers
• Instrumentation amplifiers

Features

• Low resistance values
• High power rating
• Tight tolerance
• Low Temperature Coefficient of Resistance (TCR)
• Thick film construction
• Surface mount technology (SMT)
• RoHS compliant

Benefits

• Accurate current measurement
• Stable performance over temperature
• Reduced power loss
• Space-saving SMT design
• Reliable operation in harsh environments
• Meets environmental regulations

Specifications

The resistor has a resistance value of 0.020 ohms (20 milliohms). It is available in a 2512 chip size. It features tight tolerances and a low TCR, ensuring accurate and stable performance over a wide temperature range. The power rating allows the resistor to handle significant current without overheating or changing its resistance value. The thick film construction and SMT design provide excellent reliability and ease of assembly.

The LRC-LRF2512-01-R020-F is ideal for applications where accurate current measurement and stable performance are critical. Its low resistance value, tight tolerance, and low TCR make it a suitable choice for a wide range of electronic circuits. The high power rating ensures reliable operation even in demanding applications.
