The SMR-1R00-1.0 is a precision shunt resistor manufactured by Isabellenhütte Heusler GmbH & Co. KG, known for their expertise in producing high-quality resistive components. This shunt resistor is specifically designed for accurate current sensing in a diverse range of applications. It boasts low resistance, high precision, and excellent long-term stability, making it ideal for demanding measurement and control systems.

Applications:

• Power Supplies: Used for precise current monitoring and control within power supplies, contributing to stable and efficient operation.
• Motor Drives: Integrated into motor drive systems to facilitate accurate measurement of motor current, enabling precise torque control.
• Battery Management Systems (BMS): Utilized in BMS to monitor battery charging and discharging currents, optimizing battery performance and safety.
• Inverters: Applied in inverters for current sensing and control to achieve efficient and reliable power conversion.
• Welding Equipment: Employed in welding machines to provide accurate current feedback, enhancing control precision.
• High Precision Measurement Instruments: Integrated into precision instruments to ensure highly accurate current measurements.

Features:

• Low Resistance Value: The 1R00 designation indicates a resistance value of 1 Ohm.
• High Precision: Offers exceptional accuracy in current measurement owing to its precisely defined resistance.
• Excellent Long-Term Stability: Maintains its resistance value consistently over prolonged periods and under diverse operating conditions.
• Low Temperature Coefficient: Exhibits minimal variation in resistance value despite temperature fluctuations.
• Four-Terminal Connection: Employs a four-terminal (Kelvin) connection to effectively eliminate errors caused by lead resistance.
• High Pulse Load Capability: Designed to withstand high current pulses without significant performance degradation.

Benefits:

• Accurate Current Measurement: Delivers highly accurate current measurements, crucial for precise system control and monitoring.
• Improved System Performance: Enables optimized system performance and efficiency through precise current sensing.
• Enhanced Stability: Guarantees consistent and reliable measurements over extended operational periods thanks to its long-term stability.
• Reduced Measurement Errors: Minimizes measurement errors by utilizing a four-terminal connection, thereby eliminating lead resistance effects.
• Robust Design: Ensures dependable operation in demanding applications due to its ability to withstand high pulse loads.

Additional Details:

The SMR-1R00-1.0 shunt resistor is typically constructed from a high-quality metal alloy, chosen for its exceptional resistance stability and minimal temperature coefficient. The four-terminal connection is vital for accurate measurements, as it removes the impact of lead resistance. Current is applied through the two outer terminals, while the voltage drop across the resistor is measured via the two inner terminals. The “1.0” suffix may refer to the tolerance or a particular revision. This resistor is typically mounted on a PCB using surface mount technology (SMT). Isabellenhütte shunt resistors are well-regarded for their durability and reliability, establishing the SMR-1R00-1.0 as a reliable solution for precision current sensing across various industrial and scientific fields. It is important to use appropriate soldering techniques for establishing a robust electrical and thermal connection with the PCB.
