CPC1004N Clare, Inc. CPC1004N Real Image
Same model may have multiple batches, images only for reference.
CPC1004N Clare, Inc. CPC1004N Real Image
CPC1004N Clare, Inc. CPC1004N Real Image
Same model may have multiple batches, images only for reference.

CPC1004N

Part No CPC1004N
Manufacturer IXYS
Catalog Solid State Relays
Description SSR RELAY SPST-NO 300MA 0-100V / Solid State SPST-NO (1 Form A) 4-SOP (0.150", 3.81mm)
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Relays - Solid State Relays
Mfr IXYS
Series CPC, OptoMOS®
Package Tube
Product Status Active
Mounting Type Surface Mount
Circuit SPST-NO (1 Form A)
Output Type DC
Voltage - Input 1.2VDC
Voltage - Load 0 V ~ 100 V
Load Current 300 mA
On-State Resistance (Max) 4 Ohms
Termination Style Gull Wing
Package / Case 4-SOP (0.150", 3.81mm)
Supplier Device Package 4-SOP
Base Product Number CPC1004
Standard Package 100 pcs
MSL Level 3 (168 Hours)
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8536.41.0030
California Prop 65 Warning Information
Win Source Part Number 580097-CPC1004N
Ultra Librarian 3D Model Ultra Librarian CPC1004N CAD Model

Description

The CPC1004N is a solid-state relay from the CPC series by IXYS.

  • Series: CPC
  • Configuration: SPST-NO
  • On-State Resistance (Max): 4 Ohms
  • Load Current (Max): 300 mA
  • Voltage Load: 0 V to 100 V
  • Voltage Input: 1.2 VDC
  • Output: DC
  • Mounting Type: Surface Mount
  • Package: 4-SOP
  • Packaging: Tube (100 pieces)
  • Applications: Industrial control, telecommunications, and medical equipment
  • Product Status: Active
  • REACH: Unaffected
