The JST Sales America Inc. 08FLH-RSM1-TB(LF)(SN) is an 8-position, 1.25mm pitch, SMT (Surface Mount Technology) header connector designed for board-to-cable connections in compact electronic devices. The 'LF' denotes Lead-Free and 'SN' denotes Tin plating.

Applications:

• Mobile Phones: Connects internal components and provides external interfaces.
• Digital Cameras: Connects image sensors, displays, and other modules.
• Laptop Computers: Used for internal connections and external ports.
• Small Electronic Devices: Suitable for various compact electronic devices requiring reliable connections.

Features:

• 8 Positions: Provides eight individual connection points.
• 1.25mm Pitch: Compact pitch allows for high-density connections in small spaces.
• SMT Mounting: Designed for surface mount assembly on PCBs.
• Header Connector: Provides a connection point for mating connectors.
• Lead-Free: RoHS compliant, ensuring environmental friendliness.

Benefits:

• Compact Design: Small size allows for use in space-constrained applications.
• Reliable Connection: Provides a secure and stable connection between boards and cables.
• Easy Assembly: SMT mounting simplifies assembly process.
• Environmentally Friendly: Lead-free construction complies with RoHS regulations.

Additional Details:

The 08FLH-RSM1-TB(LF)(SN) connector has a voltage rating of 50V AC/DC and a current rating of 1.0A per contact. The contact material is typically made of phosphor bronze with tin plating. The insulator material is usually made of high-temperature thermoplastic, allowing for reflow soldering. It is important to consult the datasheet for detailed mechanical and electrical specifications, as well as recommended soldering profiles. These connectors are commonly used in high-volume production environments where automated assembly processes are employed. The 1.25mm pitch and low profile are ideal for minimizing the overall size of electronic devices.
