BM20B-SRDS-A-G-TF Real Image
Same model may have multiple batches, images only for reference.

BM20B-SRDS-A-G-TF

Part No BM20B-SRDS-A-G-TF
Manufacturer JST Sales America Inc.
Catalog Rectangular Connectors
Description CONN HEADER SMD 20POS 1MM / Connector Header Surface Mount 20 position 0.039" (1.00mm)
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Connectors, Interconnects - Rectangular Connectors - Headers, Male Pins
Mfr JST Sales America Inc.
Series SHD
Package Tape & Reel (TR)Cut Tape (CT)
Product Status Obsolete
Connector Type Header
Contact Type Male Pin
Pitch - Mating 0.039" (1.00mm)
Number of Positions 20
Number of Rows 2
Number of Positions Loaded All
Style Board to Cable/Wire
Shrouding Shrouded - 4 Wall
Mounting Type Surface Mount
Termination Solder
Fastening Type Push-Pull
Insulation Height 0.167" (4.25mm)
Contact Shape Square
Contact Finish - Mating Gold
Contact Material Phosphor Bronze
Insulation Material Polyamide (PA), Nylon, Glass Filled
Features Board Guide, Pick and Place, Solder Retention
Temperature Range - Operating -25°C ~ 85°C
Material Flammability Rating UL94 V-0
Insulation Color Natural
Current Rating (Amps) 1A
Voltage Rating 50V
Mated Stacking Heights 6.3mm
Standard Package 1,250 pcs
MSL Level 1 (Unlimited)
ECCN EAR99
HTSUS 8536.69.4040
Win Source Part Number 913382-BM20B-SRDS-A-G-TF
Ultra Librarian 3D Model Ultra Librarian BM20B-SRDS-A-G-TF CAD Model

Description

The 913382-BM20B-SRDS-A-G-TF is a 20-position male pin header connector from JST Sales America Inc.

  • Series: SHD series of rectangular connectors
  • Suitable for: board to cable/wire applications
  • Fastening Type: push-pull
  • Mounting: surface mount mounted
  • Contact Material: phosphor bronze
  • Contact Finish: gold for mating
  • Voltage Rating: 50V
  • Current Rating: 1A
  • Insulation Material: polyamide (PA), nylon, and glass filled
  • Flammability Rating: UL94 V-0
  • Contact Shape: square
  • Insulation Height: 0.167" (4.25mm)
  • Status: obsolete product
  • Standard Package: 1,250 pcs
