Same model may have multiple batches, images only for reference.
S4B-ZR(LF)(SN) Real Image
Same model may have multiple batches, images only for reference.

S4B-ZR(LF)(SN)

Part No S4B-ZR(LF)(SN)
Manufacturer JST Sales America Inc.
Catalog Circular Connectors - Housings
Description CONN HEADER R/A 4POS 1.5MM / Connector Header Through Hole, Right Angle 4 position 0.059" (1.50mm)
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Connectors, Interconnects>Rectangular Connectors - Headers, Male Pins
Mfr JST Sales America Inc.
Series ZH
Package Bulk
Connector Type Header
Contact Type Male Pin
Pitch - Mating 0.059" (1.50mm)
Number of Positions 4
Number of Rows 1
Number of Positions Loaded All
Style Board to Cable/Wire
Shrouding Shrouded - 4 Wall
Mounting Type Through Hole, Right Angle
Termination Solder
Fastening Type Detent Lock
Contact Length - Mating 0.094" (2.40mm)
Contact Length - Post 0.106" (2.69mm)
Insulation Height 0.146" (3.70mm)
Contact Shape Circular
Contact Finish - Mating Tin
Contact Finish - Post Tin
Contact Material Brass
Insulation Material Polyamide (PA66), Nylon 6/6, Glass Filled
Temperature Range - Operating -25°C ~ 85°C
Material Flammability Rating UL94 V-0
Insulation Color Natural
Current Rating (Amps) 1A
Voltage Rating 50V
Base Product Number S4B-ZR
MSL Level 1 (Unlimited)
ECCN EAR99
HTSUS 8536.69.4040
Other Names 455-1671,(Q)S4B-ZR(LF)(SN),S4BZRLFSN
Standard Package 2,000
Win Source Part Number 1090165-S4B-ZR(LF)(SN)
Ultra Librarian 3D Model Ultra Librarian S4B-ZR(LF)(SN) CAD Model

Description

The ZH series 4 position male pin header connector is a through-hole, right angle connector designed for board-to-cable/wire applications.

  • Number of Positions: 4
  • Mounting Type: Through Hole
  • Angle: Right Angle
  • Application: Board-to-Cable/Wire
  • Fastening Type: Detent Lock
  • Contact Material: Brass
  • Mating Finish: Tin
  • Insulation Material: Polyamide (PA66), Nylon 6/6, Glass Filled
  • Voltage Rating: 50V
  • Current Rating: 1A
  • Insulation Height: 0.146" (3.70mm)
  • Contact Length (Mating): 0.094" (2.40mm)
  • Contact Length (Post): 0.106" (2.69mm)
  • RoHS Compliant: Yes
