The GN1G-TR is a PNP Epitaxial Planar Transistor manufactured by KEC. This transistor is designed for general-purpose amplification and switching applications.

Applications:

• Amplifier circuits
• Switching circuits
• Driver stages
• Load switches
• DC-DC converters

Features:

• High collector current (IC = -1A)
• Low saturation voltage (VCE(sat) = -0.5V max at IC = -1A)
• High current gain (hFE = 100-300)
• Complementary to NPN transistor
• Small SOT-23 package

Benefits:

• Suitable for a wide range of amplification and switching applications.
• Efficient switching due to low saturation voltage.
• High current gain simplifies circuit design.
• Compact size allows for high-density mounting.
• Cost-effective general-purpose transistor.

Additional Details:

The GN1G-TR is housed in a SOT-23 surface mount package. It has a collector-base voltage (VCBO) of -50V and a collector-emitter voltage (VCEO) of -40V. It is RoHS compliant. The device is commonly used in portable electronic devices and other applications where space is limited.
