Same model may have multiple batches, images only for reference.
MPXV1D1264LR22 Real Image
Same model may have multiple batches, images only for reference.

MPXV1D1264LR22

Part No MPXV1D1264LR22
Manufacturer Kemet
Catalog Fixed Inductors
Description FIXED IND 220NH 53A 1.1MOHM SMD / 220 nH Shielded Inductor 53 A 1.1mOhm Max Nonstandard
Datasheet
MPXV1D1264LR22 Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Inductors, Coils, Chokes>Fixed Inductors
Mfr KEMET
Series MPXV
Package Tape & Reel
Material - Core Metal Composite
Inductance 220 nH
Tolerance ±20%
Current Rating (Amps) 53 A
Current - Saturation (Isat) 100A
Shielding Shielded
DC Resistance (DCR) 1.1mOhm Max
Frequency - Self Resonant 90MHz
Ratings AEC-Q200
Temperature Range - Operating -55°C ~ 155°C
Inductance Frequency - Test 100 kHz
Mounting SMD (SMT)
Package / Case Nonstandard
Dimension 0.520" L x 0.492" W (13.20mm x 12.50mm)
Height - Seated (Max) 0.252" (6.40mm)
Base Product Number MPXV1D1264
MSL Level 1 (Unlimited)
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8504.50.8000
Other Names 399-MPXV1D1264LR22TR,UPI2X11264VR22,399-MPXV1D1264LR22CT,399-MPXV1D1264LR22DKR
Standard Package 250
Win Source Part Number 1054555-MPXV1D1264LR22
Ultra Librarian 3D Model Ultra Librarian MPXV1D1264LR22 CAD Model

Description

The MPXV series inductors are fixed inductors with a shielding feature.

  • Inductance: 220 nH
  • DC Resistance: 1.1mOhm max
  • Height: 0.252 inches
  • Package/Case: non-standard
  • Tolerance: ±20%
  • Frequency Self-Resonant: 90MHz
  • Current Rating: 53A
  • AEC-Q200 Rated: yes
  • Core Material: metal composite
  • Inductance Frequency-Test: 100 kHz
  • Operating Temperature: -55°C to 155°C
  • Packaging: tape and reel
  • Standard Package: 250
