Same model may have multiple batches, images only for reference.
PHE450RB4470JR06 Kemet – Price, Stock & Datasheet
Same model may have multiple batches, images only for reference.

PHE450RB4470JR06

Part No PHE450RB4470JR06
Manufacturer Kemet
Catalog Film Capacitors
Description CAP FILM 4700PF 5% 1.6KVDC RAD
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Win Source Part Number 1521607-PHE450RB4470JR06
Supply and Demand Status Normal
Package Bulk
Applications High Frequency, Switching
Lead Spacing 0.591" (15.00mm)
Termination PC Pins
Height - Seated (Max) 0.413" (10.50mm)
Size / Dimension 0.709" L x 0.217" W (18.00mm x 5.50mm)
Case / Package Radial
Mounting Type Through Hole
Temperature Range - Operating -55°C ~ 105°C
Dielectric Material Polypropylene (PP), Metallized
Voltage Rating - DC 1600V (1.6kV)
Voltage Rating - AC 650V
Tolerance ±5%
Capacitance 4700 pF
Ultra Librarian 3D Model Ultra Librarian PHE450RB4470JR06 CAD Model

Description

N
