Part No 1059
Manufacturer Keystone Electronics
Catalog Battery Holders, Clips, Contacts
Description BATT HLDR COIN 20MM 1 CEL PC PIN / Battery Holder (Open) Coin, 20.0mm 1 Cell PC Pin
Datasheet
1059 Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Battery Products - Battery Holders, Clips, Contacts
Mfr Keystone Electronics
Series Vibra-Fit
Package Bulk
Product Status Active
Battery Type, Function Coin Cell, Holder
Style Holder (Open)
Battery Cell Size Coin, 20.0mm
Number of Cells 1
Battery Series 2032
Mounting Type PCB, Through Hole
Termination Style PC Pin
Height Above Board 0.217" (5.50mm)
Temperature Range - Operating -50°C ~ 145°C
Standard Package 1 pcs
MSL Level 1 (Unlimited)
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8536.69.4030
Win Source Part Number 853663-1059
Ultra Librarian 3D Model Ultra Librarian 1059 CAD Model

Description

The Battery Holder is a convenient and secure solution for holding and connecting coin cell batteries.

  • Coin Cell Size: 20.0mm
  • Mounting Type: PCB Through-Hole
  • Series: Vibra-Fit
