GAL22V10D-10LP Lattice Semiconductor Corporation GAL22V10D-10LP real image
Same model may have multiple batches, images only for reference.
GAL22V10D-10LP Lattice Semiconductor Corporation GAL22V10D-10LP real image
GAL22V10D-10LP Lattice Semiconductor Corporation GAL22V10D-10LP real image
Same model may have multiple batches, images only for reference.

GAL22V10D-10LP

Part No GAL22V10D-10LP
Manufacturer Lattice Semiconductor Corporation
Catalog Embedded - CPLDs (Complex Programmable Logic Devices)
Description SPLD GAL Family 10 Macro Cells 5V 24-Pin PDIP / High Performance E2CMOS PLD Generic Array Logic | IC CPLD 10MC 10NS 24DIP
Datasheet
GAL22V10D-10LP Datasheet
Sample
Rohs State Need to verify
ECAD Module
Need Help

Products specifications Report Issue?

Categories Integrated Circuits
Manufacturer Lattice Semiconductor Corporation
Packaging Bulk
Status Obsolete
Programmable Type EE PLD
Delay Time tpd(1) Max 10.0ns
Voltage Supply - Internal 4.75V ~ 5.25V
Number of Macrocells 10
Temperature Range - Operating 0°C ~ 75°C
Mounting Style Through Hole
Manufacturer Package 24-DIP
Supplier Device Package 24-PDIP
Family Part Number GAL22V10
Manufacturer Pack Quantity 300
MSL Level 3 (168 Hours)
Win Source Part Number 1176834-GAL22V10D-10LP
Manufacturer Homepage www.latticesemi.com
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Limited
Family Name GAL22V10D
Introduction Date August 22, 2008
Country of Origin Indonesia, Philippines
Estimated EOL Date Obsolete / End of life
Ultra Librarian 3D Model Ultra Librarian GAL22V10D-10LP CAD Model

Description

The GAL22V10D-10LP is an obsolete programmable logic device manufactured by Lattice Semiconductor Corporation.

  • Supply and Demand Status: Limited
  • RoHS: Compliant
  • Manufacturer Homepage: www.latticesemi.com
  • Delay Time tpd(1) Max: 10.0ns
  • Voltage - Supply: 4.75V ~ 5.25V
  • Number of Macrocells: 10
  • Lifecycle Status: Obsolete
