The LCMXO2-4000HC-6QN84I is a low-power, instant-on, non-volatile Field Programmable Gate Array (FPGA) from Lattice Semiconductor Corporation, part of the MachXO2 family. This FPGA is designed for a wide range of applications requiring flexible logic implementation, high performance, and low power consumption.

Applications

• Consumer Electronics
• Industrial Control
• Automotive Systems
• Communication Equipment
• Medical Devices

Features

• 4320 Look-Up Tables (LUTs): Provides ample logic resources for implementing complex digital circuits.
• Non-Volatile Configuration: Enables instant-on operation and eliminates the need for external configuration memory.
• Low Power Consumption: Designed for low-power applications.
• Embedded Memory: Includes embedded SRAM for data storage.
• Flexible I/O: Supports a wide range of I/O standards.
• High-Speed Performance: Provides high-speed switching and processing capabilities.
• Advanced Packaging: Available in a QFN84 package for space-constrained applications.

Benefits

• Flexibility and Customization: Allows for implementing custom logic functions.
• Instant-On Operation: Enables immediate operation upon power-up.
• Low Power Consumption: Extends battery life in portable devices.
• Reduced System Cost: Eliminates the need for external configuration memory.
• Simplified System Design: Easy to integrate into various systems.

Additional Details

The LCMXO2-4000HC-6QN84I operates on a core voltage of typically 1.2V. It is designed to be programmed using standard FPGA design tools. The non-volatile configuration memory allows the FPGA to retain its configuration even when power is removed, enabling instant-on operation. The device includes embedded SRAM memory blocks for data storage and processing. The flexible I/O structure allows for interfacing with a wide range of external devices and interfaces. The QFN84 package provides a small footprint, making it suitable for space-constrained applications. The FPGA is commonly used in applications where flexibility, low power consumption, and instant-on operation are required, such as in consumer electronics, industrial control, and communication equipment.
