The LT1167IS8#PBF is a single-resistor gain programmable, high-precision instrumentation amplifier that offers an exceptional combination of flexibility, performance, and ease-of-use. Manufactured by Linear Technology, a leader in analog integrated circuits, this product is designed for a wide range of applications, including medical equipment, industrial process controls, and data acquisition systems.

Key Features

• Single Gain Set Resistor: The LT1167's gain is easily set by a single external resistor, which significantly simplifies the circuit design and allows for easy adjustments or calibration.
• High Precision: With a low input offset voltage, low noise, and low total harmonic distortion, the LT1167IS8#PBF ensures high-fidelity signal amplification, making it ideal for precision applications.
• Low Power Consumption: The device operates with a quiescent current of just 1.3mA, making it suitable for battery-powered and portable applications without compromising performance.
• Wide Supply Range: It can be powered from a single 2.3V to 36V supply or dual ±2.3V to ±18V supplies, providing flexibility in various power environments.
• High CMRR: With a common-mode rejection ratio (CMRR) of 116dB, the LT1167IS8#PBF effectively minimizes the influence of unwanted common-mode signals.
• Robust Output Drive: Capable of driving heavy loads, the LT1167 provides an output current of up to 20mA.

Product Specifications

The LT1167IS8#PBF is a testament to Linear Technology's commitment to high-quality, precision analog ICs. Its robustness, combined with its ease of use, makes it an excellent choice for designers who require a reliable and flexible solution for their instrumentation amplification needs.
