The LT3461ES6 is a compact, high-efficiency, step-up DC/DC converter from Linear Technology, designed to provide significant performance in a small package. This versatile component is ideal for applications requiring a compact power solution that can efficiently convert lower voltage inputs to higher voltage outputs.

Key Features:

• Adjustable Output Voltage: The LT3461ES6 allows for an adjustable output voltage that can be set with a single external resistor, providing flexibility for various applications.
• Internal 1.3A Power Switch: Its internal 1.3A power switch facilitates the delivery of output currents up to several hundred milliamps, depending on input voltage and output voltage settings.
• Wide Input Voltage Range: It operates from an input voltage range of 2.5V to 16V, making it compatible with a variety of low voltage sources including single-cell lithium-ion batteries.
• High Switching Frequency: A high switching frequency of 1.3MHz allows the use of small, low-cost capacitors and inductors, reducing the overall footprint and cost of the power supply design.
• Integrated Soft-Start Function: The soft-start function limits the inrush current during startup, which provides additional protection to the power source and the LT3461ES6 itself.

Applications:

The LT3461ES6 is suitable for a wide range of applications, including but not limited to:

• Portable Electronics
• Handheld Scanners
• Digital Cameras
• Medical Diagnostic Equipment
• Wireless Modems
• GPS Devices

Package Information:

The device is offered in a small 6-lead SOT-23 package, which is designed for space-constrained applications. The compact form factor, combined with the high level of integration, minimizes the need for additional external components and reduces the overall solution size.

Quality and Reliability:

Linear Technology is known for its high-quality products, and the LT3461ES6 is no exception. It is designed to meet stringent quality and reliability standards, ensuring stable and reliable performance in diverse operating conditions.
