Products specifications

Categories Integrated Circuits
Manufacturer Linear Technology
Packaging Tube/Rail
Status Active
Filter Type Universal Switched Capacitor
Frequency - Cutoff or Center 30kHz
Number of Filters 2
Filter Order 4th
Supply Voltage - Operating ±2.37 V to 5 V
Mounting Through Hole
Case / Package 20-PDIP
Win Source Part Number 072422-LTC1060CN
Ultra Librarian 3D Model Ultra Librarian LTC1060CN CAD Model

Description

The LTC1060CN from Linear Technology is a high-performance, universal dual filter building block designed to provide users with a versatile and precise filtering solution. This integrated circuit (IC) is well-suited for a wide range of applications including signal processing, telecommunications, and instrumentation, making it a staple in the electronics industry.

Key Features:

  • Clock-Tunable Cutoff Frequency: The LTC1060CN offers a clock-tunable cutoff frequency that ranges from 0.1Hz to 25kHz, allowing for a flexible adjustment of the filter's response to suit various application needs.
  • Dual Filter Design: This IC features a dual filter design, which means it can be configured as two independent filters or combined to form a higher-order filter, providing users with greater design flexibility.
  • Low Noise: With its low noise performance, the LTC1060CN ensures a clean signal output, which is essential for high-fidelity audio applications and precise measurement instruments.
  • No External Components Required: One of the significant advantages of the LTC1060CN is that it does not require any external components such as resistors or capacitors to set the filter's frequency, thus simplifying circuit design and reducing board space.
  • Multiple Filter Responses: The device can be configured to provide various filter responses, including low-pass, high-pass, band-pass, and notch filters, making it an all-in-one solution for filtering tasks.

Applications:

  • Audio Processing
  • Data Communications
  • Signal Conditioning
  • Anti-Aliasing Filters
  • Phase-Locked Loops (PLLs)

The LTC1060CN is housed in a narrow 16-pin DIP package, ensuring compatibility with standard breadboards and sockets. Its robust design and reliable performance have made it a preferred choice for engineers and designers looking for a high-quality, easy-to-use filtering solution.

Whether you are working on a sophisticated audio system, designing a complex signal processing circuit, or simply need a reliable filter for your project, the LTC1060CN from Linear Technology is an excellent choice that promises to deliver performance and versatility in a compact form factor.
