Products specifications Report Issue?

RoHS State Request Verification
Manufacturer Linear Technology
Win Source Part Number 1208522-LTC2626CDD
Manufacturer Homepage www.linear.com
Popularity Medium
Supply and Demand Status Limited
Application Field Used in Power Management, Signal Processing, Communications & Networking, Portable Devices
Ultra Librarian 3D Model Ultra Librarian LTC2626CDD CAD Model

Description

LTC2626CDD: 16-Bit, Dual Rail-to-Rail DACs with I2C Interface

The LTC2626CDD from Linear Technology is a high-precision, dual 16-bit Digital-to-Analog Converter (DAC) that offers exceptional performance with a rail-to-rail output range. Enclosed in a compact 10-lead DFN package, this product is designed for space-constrained applications requiring high-resolution analog output. The LTC2626CDD is ideal for advanced industrial control systems, automated test equipment, and high-end audio applications where precise signal control is paramount.

Key to the LTC2626CDD's performance is its I2C-compatible serial interface, which supports standard (100kHz), fast (400kHz), and high-speed (3.4MHz) modes. This flexibility allows the DAC to easily interface with a wide range of microcontrollers and digital systems. Furthermore, the device includes a built-in reference with low drift and noise, ensuring stable and accurate output voltages over time and temperature variations.

The LTC2626CDD incorporates a variety of features to enhance its functionality and ease of use. Each of the two DACs can be independently programmed using the I2C interface, allowing for precise control of output voltages from 0V to the reference voltage. In addition, the device offers a Power-On Reset circuit that ensures the DAC output powers up to zero volts and remains there until a valid write takes place. This feature is critical for applications where a predictable startup state is necessary.

For applications demanding low power consumption, the LTC2626CDD excels with its shutdown feature, which reduces power consumption to 1μA per DAC when not in use. This makes it well-suited for battery-powered devices and energy-efficient systems.

Linear Technology's attention to detail is evident in the LTC2626CDD's design, which provides guaranteed monotonic performance over the entire operating temperature range. Additionally, the device's robust output drive capability and thermal protection make it reliable in the most demanding environments.

In conclusion, the LTC2626CDD represents a blend of precision, flexibility, and reliability, making it an excellent choice for designers looking to integrate high-quality, dual-channel DAC functionality into their systems.
