Product Overview: LTC3114EDHC-1#PBF by Linear Technology

The LTC3114EDHC-1#PBF is a high-performance, buck-boost DC/DC converter designed by Linear Technology to provide efficient power management for a wide range of applications. This versatile component is capable of operating with an input voltage range of 2.7V to 15V, making it ideal for systems that require a stable output voltage even when the input supply is not well regulated or varies significantly.

Key Features

• Wide Input Voltage Range: Operates from 2.7V to 15V, suitable for single-cell Li-Ion, multi-cell alkaline or NiMH, and 12V systems.
• Versatile Output: Adjustable output voltage from 0.8V to 5.5V, allowing use with a variety of loads and devices.
• High Efficiency: Up to 95% efficiency, ensuring minimal heat generation and maximum battery life.
• High Output Current: Delivers up to 2A of continuous output current over the entire input voltage range.
• Low Noise: Low noise buck-boost operation makes it suitable for RF and precision analog applications.
• Programmable Frequency: Switching frequency can be programmed between 400kHz and 2MHz or synchronized to an external clock.
• Robust Protection Features: Includes over-temperature protection, short-circuit protection, and overvoltage lockout.
• Compact Package: Comes in a 16-lead DFN package with a 3mm x 5mm footprint.

Applications

The LTC3114EDHC-1#PBF is suitable for a variety of applications that require a stable and efficient power supply. These include:

• Portable instruments
• Industrial equipment
• Medical devices
• Automotive power systems
• Point-of-load power supplies
• Handheld devices

Quality and Reliability

Linear Technology is renowned for its commitment to quality and reliability, and the LTC3114EDHC-1#PBF is no exception. It is designed to meet the stringent requirements of even the most demanding applications, ensuring consistent performance and longevity. Whether for commercial, industrial, or automotive use, this DC/DC converter stands as a testament to Linear Technology's dedication to excellence in power management solutions.
