Products specifications

Categories Integrated Circuits (ICs)
Manufacturer Linear Technology
Packaging Tube
Type Hot Swap Controller, Monitor
Number of Channels 1
Internal Switch(s) No
Applications ATCA, MicroTCA
Programmable Features Auto Retry, Current Limit, Fault Timeout, Latched Fault, OVP, UVLO
Operating Supply Voltage 2.9 V ~ 26.5 V
Operating Temperature Range -40°C ~ 85°C
Operating Supply Current 1.6mA
Mounting SMD
Package 16-SSOP (0.154", 3.90mm Width)
Manufacturer Package 16-SSOP
Feature Pins FB, /FLT, IMON, ISET, OV, PG, SOURCE, TIMER, UV
Win Source Part Number 783944-LTC4218IGN#PBF
Popularity Medium
Supply and Demand Status Limited
Family Name LTC4218
Introduction Date January 21, 2008
ECCN EAR99
Country of Origin Malaysia
Halogen Free Compliant
Estimated EOL Date 2031
Ultra Librarian 3D Model Ultra Librarian LTC4218IGN#PBF CAD Model

Description

LTC4218IGN#PBF - Hot Swap Controller from Linear Technology

The LTC4218IGN#PBF is a sophisticated hot swap controller designed by Linear Technology, aimed at managing the insertion and removal of boards in live backplane systems. This component ensures safe and controlled power-up sequencing, which is crucial for preventing damage to both the electronic boards and the power supply due to inrush currents or voltage spikes.

Key Features

  • Adjustable Supply Voltage: The LTC4218IGN#PBF supports an adjustable supply voltage range from 2.9V to 26.5V, making it versatile for various applications.
  • Current Limiting: It features an adjustable analog foldback current limit, which helps protect the power source and the circuitry during overcurrent conditions.
  • Overcurrent Protection: The product incorporates both fast trip and slow blow overcurrent protection to ensure the safety and longevity of electronic components.
  • Gate Voltage Monitoring: With its gate voltage monitoring capability, the LTC4218IGN#PBF provides a controlled MOSFET gate voltage ramp-up for smooth board insertion.
  • Power Good Output: It includes a 'power good' output signal, which allows for downstream load enabling once the board is safely powered up.
  • High Temperature Operation: This device is capable of operating over a wide temperature range, making it suitable for industrial environments.
  • Compact Package: The LTC4218IGN#PBF is available in a compact 16-lead SSOP package, which is space-efficient for high-density board designs.

Applications

The LTC4218IGN#PBF is ideal for a range of applications that require reliable power management during the insertion of circuit boards. These include:

  • RAID Systems
  • Server Backplanes
  • Network Routers and Switches
  • Hot Swap Redundant Systems
  • Industrial Equipment

Linear Technology's LTC4218IGN#PBF hot swap controller is engineered to provide a seamless and protected interface between the power supplies and the boards being inserted or removed. With its robust feature set and flexible application range, it is an essential component for system designers looking to enhance the reliability and safety of their hot-swap operations.
