Products specifications Report Issue?

Categories Power Supplies - Board Mount
Manufacturer Linear Technology
Series μModule
Packaging Tray
Type Non-Isolated PoL Module
Number of Outputs 1
Input Voltage MIN 4.5V
Voltage Input MAX 20V
Voltage - Output 1 0.6 ~ 5 V
Current - Output (Maximum) 12A
Applications ITE (Commercial)
Features OVP, SCP, UVLO
Operating Temperature Range -40°C ~ 85°C
Efficiency 95%
Mounting SMD
Package 118-BLGA Module
Size 0.59" L x 0.59" W x 0.11" H (15.0mm x 15.0mm x 2.8mm)
Manufacturer Package 118-LGA (15x15)
Manufacturer Homepage www.linear.com
Win Source Part Number 710959-LTM4601EV#PBF
Popularity Medium
Supply and Demand Status Limited
Family Name LTM4601
Introduction Date January 26, 2007
ECCN EAR99
Country of Origin Malaysia
Halogen Free Compliant
Estimated EOL Date 2028
Ultra Librarian 3D Model Ultra Librarian LTM4601EV#PBF CAD Model

Description

Product Overview: LTM4601EV#PBF

The LTM4601EV#PBF is a high-performance power management solution from Linear Technology, designed to cater to the demanding needs of modern electronic applications. This efficient DC/DC µModule (micromodule) regulator is a complete system-in-package (SiP) that combines a switching power controller, power MOSFETs, inductors, and all the supporting components in a compact LGA package. This design simplifies the implementation of a high-efficiency power supply with a small footprint on the PCB.

Key Features

  • Wide Input Voltage Range: The LTM4601EV#PBF operates from an input voltage range of 4.5V to 20V, making it versatile for a variety of supply voltages.
  • High Output Current: This µModule regulator is capable of delivering up to 10A of continuous output current, suitable for high-power applications.
  • Adjustable Output Voltage: The output voltage can be adjusted from 0.6V to 5V, providing flexibility for different voltage requirements.
  • High Efficiency: With an integrated synchronous buck regulator topology, the LTM4601EV#PBF achieves high conversion efficiency, reducing power loss and heat dissipation.
  • Integrated Components: The inclusion of internal power MOSFETs, inductors, and compensation circuitry simplifies design and reduces external component count.
  • Thermal Performance: The LGA package enhances thermal performance, aiding in heat dissipation for reliable operation even at full load.

Applications

The LTM4601EV#PBF is ideal for use in a wide range of applications where high efficiency, compact size, and ease of use are critical. Typical applications include:

  • Telecommunications infrastructure
  • Networking equipment
  • Servers and storage systems
  • Industrial equipment
  • Medical devices

Reliability and Quality

Linear Technology is known for its commitment to quality, and the LTM4601EV#PBF is no exception. It is designed to meet stringent performance standards and is subject to rigorous testing to ensure reliability in diverse operating conditions.

With its robust feature set and integrated design, the LTM4601EV#PBF from Linear Technology offers a powerful, efficient, and reliable solution for advanced power management requirements.
