The LTV-1009-TP1-G is an optocoupler manufactured by Lite-On Inc. This device consists of an infrared emitting diode optically coupled to a phototransistor. It is designed for electrical isolation between input and output circuits, offering high insulation voltage and reliable signal transmission. It's suitable for various applications where electrical isolation is required.

Applications

• Digital logic input isolation
• Microprocessor input/output isolation
• Power supply feedback control
• Interfacing different voltage levels
• General purpose switching circuits

Features

• High isolation voltage (5000 Vrms)
• Current transfer ratio (CTR) 50-600%
• Operating temperature: -55°C to +100°C
• DIP-4 package
• RoHS Compliant

Benefits

• Provides electrical isolation between circuits
• Protects sensitive circuits from high voltage
• Reduces ground loop noise
• Enhances system reliability
• Easy to implement in circuit designs

Technical Specifications

The LTV-1009-TP1-G features a high isolation voltage of 5000 Vrms, ensuring robust electrical isolation. The current transfer ratio (CTR) ranges from 50% to 600%, allowing for efficient signal transfer. The operating temperature range is -55°C to +100°C, suitable for a variety of operating environments. The device is housed in a standard DIP-4 package for easy through-hole mounting. This optocoupler is commonly used in applications where electrical isolation is crucial, such as interfacing digital logic circuits with high-voltage power supplies. The infrared emitting diode provides efficient signal transmission to the phototransistor, ensuring reliable switching. More detailed specifications are available in the datasheet.

Lite-On's optocouplers are known for their reliable performance and wide range of applications.
