0154003.DR Littelfuse Inc. 0154003.DR Real Image 0154003.DR real image
Same model may have multiple batches, images only for reference.
0154003.DR Littelfuse Inc. 0154003.DR Real Image 0154003.DR real image
0154003.DR Littelfuse Inc. 0154003.DR Real Image 0154003.DR real image
Same model may have multiple batches, images only for reference.

0154003.DR

Part No 0154003.DR
Manufacturer Littelfuse Inc.
Catalog Fuses
Description NANO2® > 154 OMNI-BLOK® Fuse and Holder Combination | FUSE BOARD MNT 3A 125VAC/VDC SMD
Datasheet
0154003.DR Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Circuit Protection
Manufacturer Littelfuse Inc.
Packaging Reel
Fuse Type Board Mount (Cartridge Style Excluded)
Current Rating (Amps) 3A
Voltage Rating - AC 125V
Voltage Rating - DC 125V
Response Time Fast Blow
Manufacturer Package 2-SMD, Square End Block with Holder
Mounting Style Holder, Surface Mount
Breaking Capacity at Rated Voltage 50A
Melting I2t 1.65
Approvals PSE, UL
Temperature Range - Operating -55°C ~ 125°C
Parts Dimension 0.383" L x 0.198" W x 0.150" H (9.73mm x 5.03mm x 3.81mm)
DC Cold Resistance 0.0227 Ohms
Manufacturer Pack Quantity 1
MSL Level 1 (Unlimited)
Win Source Part Number 1120473-0154003.DR
Manufacturer Homepage www.littelfuse.com
Popularity Medium
Supply and Demand Status Balance
Application Field Used in Industrial, Safety
Ultra Librarian 3D Model Ultra Librarian 0154003.DR CAD Model

Description

The 0154003.DR is a high-quality surface mount fuse from Littelfuse Inc.

  • Popularity: Medium
  • Ideal for: Protecting electronic devices from overcurrent conditions
