Same model may have multiple batches, images only for reference.

SMAJ7.0CA

Name: SMAJ7.0CA
Brand: Littelfuse Inc.
SKU: 327690
Availability: InStock
Rating: 4.85 (5 reviews)

Get a Quote

This model is a standard, industry-grade component frequently used in electronic manufacturing.

Part No	SMAJ7.0CA
Manufacturer	Littelfuse Inc.
Catalog	TVS - Diodes
Description	TVS DIODE 7VWM 12VC SMA
Datasheet	SMAJ7.0CA Datasheet
Sample
Rohs State
ECAD Module
	Add to BOM List New List Existing List This product has been added to your list. List name
Need Help

Products specifications Report Issue?

Category	Circuit Protection
Family	TVS - Diodes
Manufacturer	Littelfuse Inc.
Series	SMAJ
Packaging	Reel(TR)
Type	Zener
Bidirectional Channels	1
Voltage - Reverse Standoff (Typ)	7V
Voltage - Breakdown (Min)	7.78V
Voltage - Clamping (Max) @ Ipp	12V
Current - Peak Pulse (10/1000μs)	33.3A
Power - Peak Pulse	400W
Power Line Protection	No
Applications	General Purpose
Operating Temperature Range	-55°C ~ 150°C (TJ)
Mounting Style	SMD/SMT
Package	DO-214AC, SMA
Manufacturer Device Package	DO-214AC (SMA)
Win Source Part Number	029087-SMAJ7.0CA
Popularity	Medium
Supply and Demand Status	Limited
Application Field	Used in Communications & Networking, Computers & Computer Peripherals, Imaging, Video & Vision, Industrial
Package	Strip
Product Status	Active
Current - Peak Pulse (10/1000µs)	33.33A
Operating Temperature	-55°C ~ 150°C
Grade	-
Mounting Type	Surface Mount
Package / Case	DO-214AC (SMA)
Package	Tape & Reel (TR)
Current - Peak Pulse (10/1000µs)	33.3A
Operating Temperature	-55°C ~ 150°C (TJ)
Package / Case	DO-214AC, SMA
Supplier Device Package	DO-214AC (SMA)
Ultra Librarian 3D Model	Ultra Librarian SMAJ7.0CA CAD Model

Alternative Products

Description

The Littelfuse Inc. SMAJ7.0CA Zener diode is a unidirectional TVS diode designed to protect electronic circuits from voltage transients.

Voltage Breakdown: 7.78V
Clamping Voltage @ Peak Pulse Current: 12V @ 33.3A
Mounting: SMD/SMT
Package: DO-214AC (SMA)
Operating Temperature Range: -55°C to 150°C
Applications: Communications and networking, computers and computer peripherals, imaging, video and vision, and industrial applications
Supply and Demand: Limited
