SMCJ58CA Real Image SMCJ58CA Real Image
Same model may have multiple batches, images only for reference.
SMCJ58CA Real Image SMCJ58CA Real Image
SMCJ58CA Real Image SMCJ58CA Real Image
Same model may have multiple batches, images only for reference.

SMCJ58CA

Part No SMCJ58CA
Manufacturer Littelfuse Inc.
Catalog TVS - Diodes
Description TVS DIODE 58VWM 93.6VC DO214AB
Datasheet
SMCJ58CA Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Circuit Protection - Transient Voltage Suppressors (TVS) - TVS Diodes
Mfr Littelfuse Inc.
Series SMCJ
Package Tape & Reel
Product Status Active
Type Zener
Bidirectional Channels 1
Voltage - Reverse Standoff (Typ) 58V
Voltage - Breakdown (Min) 64.4V
Voltage - Clamping (Max) @ Ipp 93.6V
Current - Peak Pulse (10/1000µs) 16.1A
Power - Peak Pulse 1500W (1.5kW)
Power Line Protection No
Applications General Purpose
Temperature Range - Operating -55°C ~ 150°C (TJ)
Mounting Type Surface Mount
Package / Case DO-214AB, SMC
Supplier Device Package DO-214AB (SMCJ)
Standard Package 3,000 pcs
MSL Level 1 (Unlimited)
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8541.10.0080
California Prop 65 Warning Information
Win Source Part Number 668942-SMCJ58CA
Ultra Librarian 3D Model Ultra Librarian SMCJ58CA CAD Model

Description

The SMCJ58CA is a bidirectional TVS diode designed for transient voltage suppression in electronic circuits.

  • Manufacturer: Littelfuse Inc.
  • Product Name: SMCJ58CA
  • Type: Bidirectional TVS diode
  • Application: Transient voltage suppression
  • Package: Tape & reel (3,000 pieces)
  • Reverse Standoff Voltage: 58V
  • Breakdown Voltage: 64.4V
  • Clamping Voltage: 93.6V @ 16.1A (10/1000µs)
  • Power Rating: 1500W (1.5kW)
  • Mounting Type: Surface mountable
  • Package: DO-214AB, SMC
  • Status: Active
  • REACH: Unaffected
  • California Prop 65: May contain materials requiring warning
