The MX29LV160CBTC-90 is a 16-Megabit, 3V-only Flash memory device manufactured by Macronix. It is organized as 2M x 8 or 1M x 16, offering flexibility in data access. This memory is designed for applications requiring non-volatile storage, such as embedded systems, portable devices, and data storage.

Applications

• Embedded systems: Storing firmware and configuration data in embedded systems.
• Portable devices: Used in mobile phones, PDAs, and other portable devices for code and data storage.
• Data storage: Storing data in data loggers and other data storage applications.
• Industrial control: Storing program code and data in industrial control systems.
• Networking equipment: Used in routers, switches, and other networking equipment.

Features

• 16-Megabit (2M x 8/1M x 16) organization: Provides flexible data access options.
• 3V-only operation: Operates on a single 3V power supply.
• Sector erase architecture: Allows for individual sectors to be erased and reprogrammed.
• Program and erase suspend/resume: Supports program and erase suspend/resume operations.
• Hardware write protection: Provides hardware write protection to prevent accidental data corruption.
• Fast access time: Offers a fast access time of 90ns.

Benefits

• Non-volatile storage: Retains data even when power is removed.
• Low power consumption: Suitable for battery-powered applications.
• Fast access time: Enables fast data access for improved performance.
• Flexible sector erase: Allows for efficient reprogramming of individual sectors.
• Robust data protection: Hardware write protection prevents accidental data corruption.

Additional Details

The MX29LV160CBTC-90 operates with a supply voltage of 2.7V to 3.6V. The device features a sector erase architecture, allowing individual sectors to be erased without affecting other sectors. The program and erase suspend/resume feature allows for interrupting program and erase operations to read data from other sectors. The hardware write protection feature can be enabled to prevent accidental data corruption. The device is available in a TSOP package. The operating temperature range is typically from -40°C to +85°C. The datasheet provides detailed information on the electrical characteristics, timing diagrams, and programming algorithms.
