The MDIB6N70C is a high-voltage N-channel MOSFET from MagnaChip Semiconductor designed for use in various power electronics applications. This device features high voltage capability, low on-resistance, and fast switching speed, making it suitable for applications requiring high efficiency and reliability.

Applications:

• Switching Mode Power Supplies (SMPS)
• Power Factor Correction (PFC)
• DC-DC Converters
• Inverters
• Lighting Ballasts

Features:

• High Voltage: 700V drain-source voltage capability.
• Low On-Resistance: Minimizes conduction losses.
• Fast Switching Speed: Reduces switching losses and improves efficiency.
• Avalanche Ruggedness: Provides enhanced reliability.
• High dv/dt Capability: Ensures stable operation in high-frequency circuits.
• Isolated TO-220 Package: Provides electrical isolation for enhanced safety.

Benefits:

• Improved Efficiency: Low on-resistance and fast switching speed lead to higher efficiency.
• Enhanced Reliability: Avalanche ruggedness provides protection against voltage transients.
• Simplified Design: Optimized characteristics allow for simpler circuit designs.
• Reduced Heat Dissipation: Lower losses result in less heat generation.
• Increased Safety: Isolated package provides electrical isolation in high-voltage applications.

Technical Specifications:

The MDIB6N70C features a drain-source voltage (Vds) of 700V, a gate-source voltage (Vgs) of ±30V, and a continuous drain current (Id) of 6A. The on-resistance (Rds(on)) is low. The device is available in an isolated TO-220 package. The operating junction temperature ranges from -55°C to +150°C.
