The MMIS70R900PTH-E is a 700V, 0.9 Ohm Super Junction MOSFET from MagnaChip Semiconductor. It is designed for high-efficiency, high-power switching applications. The “-E” suffix indicates enhanced performance or specific characteristics compared to standard models. The Through-Hole package (PTH) allows for secure mounting and effective heat dissipation.

Applications:

• Switch Mode Power Supplies (SMPS): Used in AC-DC and DC-DC power supplies for industrial and consumer electronics applications.
• Power Factor Correction (PFC) Circuits: Improves power factor in electronic devices to meet regulatory requirements and enhance efficiency.
• Uninterruptible Power Supplies (UPS): Provides backup power in case of power outages, ensuring continuous operation of critical systems.
• Inverters: Used in solar inverters, motor drives, and other power conversion applications.
• High-Voltage Converters: Suited for applications requiring efficient voltage conversion at higher voltages.

Features:

• Low On-Resistance (RDS(on)): Minimizes conduction losses and improves overall efficiency.
• Fast Switching Speed: Reduces switching losses and allows for higher operating frequencies.
• High Avalanche Ruggedness: Provides robustness against voltage transients and surges.
• Enhanced dv/dt Capability: Improves immunity to voltage spikes and noise.
• RoHS Compliant: Meets environmental regulations for hazardous substances.

Benefits:

• Improved Efficiency: Low RDS(on) and fast switching speed contribute to reduced power losses and improved efficiency.
• Enhanced Reliability: High avalanche ruggedness and dv/dt capability provide robust performance in harsh environments.
• Simplified Thermal Management: The PTH package aids in effective heat dissipation.
• Reduced Energy Consumption: High efficiency leads to lower energy consumption and reduced operating costs.
• Environmentally Friendly: RoHS compliance ensures the product meets environmental standards.

Technical Specifications: The MMIS70R900PTH-E features a drain-source voltage (VDS) of 700V, an on-resistance (RDS(on)) of 0.9 Ohms, and enhanced switching characteristics. Please refer to the manufacturer's datasheet for comprehensive specifications, including continuous drain current and thermal resistance.
