Maxim Integrated DS32KHZN/DIP# Real-Time Clock

Introducing the DS32KHZN/DIP#, a highly precise real-time clock (RTC) module from Maxim Integrated, designed to provide timekeeping accuracy and stability for a wide range of applications. This RTC module is a compact, high-quality solution for systems that require reliable timekeeping, without the need for external timing components.

The DS32KHZN/DIP# comes in a DIP (Dual In-line Package) form factor, making it easy to integrate into various circuit board designs. This RTC is equipped with an integrated temperature-compensated crystal oscillator (TCXO) and a voltage reference, which work together to ensure the timekeeping remains accurate even under temperature variations that can commonly affect timing precision.

One of the key features of the DS32KHZN/DIP# is its low power consumption. This makes it an ideal choice for battery-powered or energy-sensitive applications where maintaining long-term operation is crucial. The device also includes a battery backup input, which allows the RTC to continue keeping time even when the primary power supply is unavailable, ensuring consistent performance and reliability.

The DS32KHZN/DIP# offers a simple I2C interface for communication, allowing it to be easily integrated into microcontroller-based systems. This interface enables straightforward reading and writing of time and date information, as well as configuration settings. The device supports a wide range of timekeeping functions including seconds, minutes, hours, day, date, month, and year, with automatic leap year compensation valid up to the year 2100.

Additional features of the DS32KHZN/DIP# include an integrated oscillator fail detection function, which provides a status bit indicating the integrity of the oscillator and alerts the system to any potential issues. This is particularly useful for systems that cannot afford to have inaccurate timekeeping.

In summary, the Maxim Integrated DS32KHZN/DIP# is a robust and accurate RTC module that is well-suited for applications such as embedded systems, industrial controls, consumer electronics, and any other systems that require precise and reliable timekeeping. Its low power consumption, simple interface, and comprehensive feature set make it a top choice for designers looking to enhance their products with dependable time management.
