Maxim Integrated MAX3232ESE+T - RS-232 Interface IC

The MAX3232ESE+T from Maxim Integrated is a high-quality RS-232 transceiver IC that is designed to meet the stringent requirements of EIA/TIA-232 and V.28/V.24 communications interfaces while operating at a single +3.3V power supply. This versatile IC is suitable for a wide range of applications in telecommunications, networking, and serial data communication systems.

Featuring a unique AutoShutdown Plus™ feature, the MAX3232ESE+T ensures low power consumption by entering a 1µA shutdown mode when the RS-232 cable is disconnected or when the transmitters of the connected peripherals are off. This makes it an ideal choice for battery-powered applications where power efficiency is critical.

The device is capable of operating at data rates up to 250kbps, which is sufficient for most serial communication needs. With its integrated charge pump circuitry, the MAX3232ESE+T generates the necessary RS-232 voltage levels (+/-5.5V) from a single 3.3V supply, thus eliminating the need for additional power sources.

The MAX3232ESE+T comes in a narrow SO package, which makes it easy to integrate into space-constrained designs. Its robust construction allows it to withstand electrostatic discharge (ESD) up to ±15kV, ensuring reliable performance and longevity in harsh environments.

This transceiver includes two drivers and two receivers, offering the flexibility to interface with various types of RS-232 communication ports. The drivers and receivers of the MAX3232ESE+T meet all EIA/TIA-232E and CCITT V.28 specifications, ensuring compatibility with a wide range of equipment.

For developers and engineers looking to implement RS-232 communication with minimal power draw and reliable data transfer, the Maxim Integrated MAX3232ESE+T is an excellent choice. Its combination of power efficiency, high data rate, and robust protection features make it a versatile component for any project requiring RS-232 connectivity.

Key Features:

• Meets EIA/TIA-232 and V.28/V.24 Specifications
• Operates from a Single +3.3V Supply
• Up to 250kbps Data Rate
• AutoShutdown Plus™ Feature for Low Power Consumption
• Integrated Charge Pump Circuitry
• ESD Protection up to ±15kV
• Two Drivers and Two Receivers
• Narrow SO Package
