MAX4232AKA-T

Part No MAX4232AKA-T
Manufacturer Maxim Integrated
Catalog Linear - Amplifiers - Instrumentation, OP Amps, Buffer Amps
Description IC OPAMP GP 10MHZ RRO SOT23-8
Datasheet
Sample
Rohs State Need to verify
ECAD Module
Need Help

Products specifications Report Issue?

Categories Integrated Circuits
Manufacturer Maxim Integrated
Packaging Reel - TR
Status Obsolete(EOL)
Amplifier Type General Purpose
Number of Circuits 2
Output Type Rail-to-Rail
Slew Rate 10 V/μs
Gain Bandwidth Product (GBP) 10MHz
Current - Input Bias 50pA
Voltage - Input Offset 850μV
Operating Supply Current 1.2mA
Channel Output Current 200mA
Supply Voltage - Operating 2.7 V to 5.5 V, ±1.35 V to 2.5 V
Temperature Range - Operating -40°C to 125°C
Mounting SMD (SMT)
Case / Package SOT-23-8
Win Source Part Number 132978-MAX4232AKA-T
Ultra Librarian 3D Model Ultra Librarian MAX4232AKA-T CAD Model

Description

The MAX4232AKA-T from Maxim Integrated is a high-precision operational amplifier (op-amp) designed to offer a blend of low power consumption and high accuracy, making it an ideal choice for battery-powered applications and precision analog circuits. This device is part of a family of op-amps that feature Maxim's patented auto-zeroing techniques, which significantly reduce the input offset voltage and eliminate the offset drift over time and temperature.

Key Features

  • Low Offset Voltage: The MAX4232AKA-T boasts an ultra-low input offset voltage, which enhances measurement accuracy in precision applications.
  • Low Power Consumption: With its focus on energy efficiency, this op-amp is optimized for battery-operated devices, ensuring minimal power drain and extended battery life.
  • Wide Supply Voltage Range: The device operates over a broad supply voltage range, accommodating various power supply requirements and simplifying power management in complex systems.
  • High Gain Bandwidth Product: The high-frequency performance of the MAX4232AKA-T is suitable for a range of applications, from audio to control systems.
  • Single or Dual-Supply Operation: Flexibility in power supply configuration allows for use in both single and dual-supply systems, making it versatile for different circuit designs.

Applications

The MAX4232AKA-T is widely used in numerous applications that demand high precision and low power. It is particularly suited for:

  • Battery-Powered Instruments
  • Sensor Signal Conditioning
  • Data Acquisition Systems
  • Portable Medical Devices
  • Industrial Process Controls
  • Audio Equipment

This op-amp comes in a compact SOT-23 package, which is suitable for space-constrained applications. The MAX4232AKA-T is characterized for operation over the extended industrial temperature range, ensuring reliable performance in a variety of environments. With its combination of features, the MAX4232AKA-T from Maxim Integrated stands out as a robust, precise, and power-efficient solution for modern electronic designs.
