MAX603ESA+T

Part No MAX603ESA+T
Manufacturer Maxim Integrated
Catalog PMIC - Voltage Regulators - Linear
Description IC REG LDO 5V/ADJ 0.5A 8SOIC
Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Integrated Circuits
Manufacturer Maxim Integrated
Packaging Reel - TR
Status Active
Output Type Adjustable (Fixed)
Number of Regulators 1
Maximum Input Voltage 11.5V
Nominal Output Voltage (Min/Fixed) 1.25V (5V)
Maximum Output Voltage 11V
Dropout Voltage-Max 0.55V @ 500mA
Output Current 500mA
Operating Supply Current 35μA
Control Features Enable
Protection Features Over Current, Over Temperature, Reverse Polarity
Temperature Range - Operating -40°C to 85°C
Regulator Topology Positive Fixed or Adjustable
Output Voltage 5V, 1.25 V to 11 V
Voltage - Dropout (Typical) 0.32V @ 500mA
Mounting SMD (SMT)
Case / Package 8-SOIC
Win Source Part Number 141178-MAX603ESA+T
Family Name MAX603
Introduction Date September 01, 1994
ECCN EAR99
Country of Origin Philippines
Halogen Free Compliant
Estimated EOL Date 2023
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Balance
Ultra Librarian 3D Model Ultra Librarian MAX603ESA+T CAD Model

Description

Maxim Integrated MAX603ESA+T Voltage Regulator

The Maxim Integrated MAX603ESA+T is a highly efficient, low-dropout linear voltage regulator designed to deliver a fixed or adjustable output from an input voltage range of 5.5V to 11.5V. This component is particularly suited for battery-powered devices, portable equipment, and other applications where extended battery life and reduced heat dissipation are critical.

One of the standout features of the MAX603ESA+T is its low quiescent current, which significantly improves the power efficiency of the device it powers, thereby extending battery life. The regulator is capable of supplying up to 500mA of output current, making it suitable for a wide range of applications from microcontrollers to portable instruments.

The device comes in a compact 8-pin SOIC package, which allows for a small footprint on the PCB, and its operational temperature range of -40°C to +85°C ensures reliability across various environmental conditions. Its thermal overload protection and short-circuit protection features provide additional safety, ensuring the regulator and the device it powers are safeguarded against potential damage caused by abnormal operating conditions.

Furthermore, the MAX603ESA+T offers a low dropout voltage, which means it can continue to provide a stable output even when the input-to-output voltage differential is minimal. This is particularly beneficial in battery-operated devices where the input voltage may decline as the battery discharges, yet a consistent output is required for proper operation.

Designers can also take advantage of the adjustable output voltage feature by connecting an external resistor divider, which allows for a custom output voltage setting that fits the specific needs of their application. This flexibility, combined with its high accuracy and low noise characteristics, makes the MAX603ESA+T a versatile choice for powering sensitive analog circuits and digital interfaces.

Overall, the Maxim Integrated MAX603ESA+T is a reliable and efficient solution for a variety of power management applications where space, efficiency, and reliability are of the essence.
