Same model may have multiple batches, images only for reference.
BSC0702LSATMA1 real image
Same model may have multiple batches, images only for reference.

BSC0702LSATMA1

Part No BSC0702LSATMA1
Manufacturer Infineon Technologies
Catalog Transistors - FETs, MOSFETs - RF
Description MOSFET N-CH 60V 100A SUPERSO8
Datasheet
BSC0702LSATMA1 Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Discrete Semiconductor Products - Transistors - FETs, MOSFETs - Single FETs, MOSFETs
Mfr Infineon Technologies
Series OptiMOS™
Package Tape & Reel
Product Status Not For New Designs
FET Type N-Channel
Technology MOSFET (Metal Oxide)
Drain to Source Voltage (Vdss) 60 V
Current - Continuous Drain (Id) @ 25°C 100A (Tc)
Drive Voltage (Max Rds On, Min Rds On) 4.5V, 10V
Rds On (Max) @ Id, Vgs 2.3mOhm @ 50A, 10V
Vgs(th) (Max) @ Id 2.3V @ 49µA
Gate Charge (Qg) (Max) @ Vgs 30 nC @ 4.5 V
Vgs (Max) ±20V
Input Capacitance (Ciss) (Max) @ Vds 4400 pF @ 30 V
FET Feature Standard
Power Dissipation (Max) 83W (Tc)
Temperature Range - Operating -55°C ~ 150°C (TJ)
Mounting Type Surface Mount
Supplier Device Package PG-TDSON-8
Package / Case 8-PowerTDFN
Base Product Number BSC0702
Standard Package 5,000 pcs
MSL Level 1 (Unlimited)
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8541.29.0095
Win Source Part Number 439073-BSC0702LSATMA1
Ultra Librarian 3D Model Ultra Librarian BSC0702LSATMA1 CAD Model

Description

The BSC0702LSATMA1 is a N-Channel MOSFET transistor from Infineon Technologies.

  • Series: OptiMOS™
  • Drain to Source Voltage (Vdss): 60V
  • Continuous Drain Current (Id) @ 25°C: 100A
  • On-Resistance (Rds On): 2.3mOhm @ 50A and 10V
  • Gate Threshold Voltage (Vgs(th)): 2.3V @ 49µA
  • Design: High power applications
  • Offers: Efficient switching performance
  • Suitable for: Use in various electronic devices such as power supplies, motor control, and lighting applications.
