Maxim Integrated MAX6695AUB Precision Dual Remote/Local Temperature Sensors

The MAX6695AUB from Maxim Integrated is a sophisticated temperature monitoring solution designed to provide precise temperature measurements for both local and remote applications. This high-accuracy sensor is ideal for system temperature monitoring, environmental control, and thermal protection in a wide range of electronic devices such as computers, servers, and telecommunications equipment.

Key Features

• Dual-Channel Monitoring: Equipped with two temperature sensors, the MAX6695AUB can simultaneously monitor the temperature of both its own die (local sensor) and a remote PN junction, typically a diode-connected transistor on a CPU, FPGA, or ASIC (remote sensor).
• High Accuracy: Offering a high degree of accuracy, the local sensor has an error of ±3°C, while the remote sensor boasts an impressive ±1°C error margin within the specified temperature range.
• Programmable Overtemperature Alarms: The device features programmable overtemperature alarm outputs for both channels, providing immediate notification of abnormal temperature conditions.
• Flexible Interface: Communication with the MAX6695AUB is facilitated through a 2-wire serial interface that is compatible with SMBus protocols, making it easy to integrate into a variety of systems.
• Wide Temperature Range: The sensor operates over a broad temperature range, with the local sensor capable of measuring from 0°C to +125°C and the remote sensor from -40°C to +125°C.
• Low Power Consumption: Designed with power efficiency in mind, the MAX6695AUB is suitable for battery-powered applications due to its low operating current.
• Compact Package: Housed in a small, 10-pin µMAX package, the MAX6695AUB minimizes the footprint on the PCB and is suitable for space-constrained applications.

Applications

The MAX6695AUB's versatile feature set makes it an excellent choice for various applications that require precise temperature monitoring and thermal management, including:

• Desktop and Notebook Computers
• Servers and Data Centers
• Telecommunication Systems
• Industrial Controllers
• Test and Measurement Equipment

With its precision dual-channel temperature sensing capabilities, the MAX6695AUB from Maxim Integrated is a reliable and efficient solution for maintaining optimal performance and protecting valuable electronic systems from thermal-related issues.
