The MAX77596ETBA+T from Maxim Integrated is a state-of-the-art, high-efficiency, synchronous step-down DC-DC converter designed to deliver a continuous output current up to 300mA. This compact, integrated solution is ideal for portable devices where space and power efficiency are at a premium.

Key Features

• Wide Input Voltage Range: The device supports an input voltage range from 2.7V to 5.5V, making it versatile for various battery technologies and systems.
• Adjustable Output Voltage: The output voltage can be adjusted from 0.8V up to the input voltage, which allows designers to tailor the voltage to the specific needs of their application.
• High Efficiency: With a peak efficiency of 90%, the MAX77596ETBA+T minimizes power loss and heat generation, extending battery life in portable applications.
• Small Footprint: The device comes in a tiny 6-pin, 1.5mm x 1.5mm TDFN package, making it one of the smallest solutions on the market for the power it delivers.
• Low Quiescent Current: The quiescent current is as low as 18µA, which is beneficial for battery-powered devices, reducing the drain on the battery when the device is in standby mode.

Applications

With its combination of high efficiency, small size, and versatility, the MAX77596ETBA+T is well-suited for a range of applications, including:

• Wearable Devices
• Bluetooth Headphones
• Portable Medical Devices
• Smart Watches
• IoT Devices

Design Support

Maxim Integrated provides comprehensive design support for the MAX77596ETBA+T, including detailed datasheets, application notes, and reference designs. Designers can take advantage of the evaluation kits and expert technical support to speed up their product development.

Ordering Information

The MAX77596ETBA+T is available in a lead-free, RoHS-compliant package and is specified over the -40°C to +85°C extended temperature range. For more information or to place an order, please contact Maxim Integrated or an authorized distributor.
