Maxim Integrated MAX9701EBP+TG45 Audio Amplifier

The MAX9701EBP+TG45 from Maxim Integrated is a high-performance, mono Class D audio amplifier that is designed to deliver exceptional sound quality with high efficiency. This compact amplifier is a perfect solution for portable applications where space is limited and power efficiency is crucial. With its advanced technology and superior design, the MAX9701EBP+TG45 is capable of driving a wide range of speakers, making it an ideal choice for a variety of audio systems.

Key Features

• High Efficiency: This Class D amplifier provides a high efficiency rate, which reduces power consumption and extends battery life in portable devices.
• Thermal Protection: Built-in thermal protection ensures the device operates within safe temperature ranges, preventing overheating and damage to the amplifier.
• Low EMI: The MAX9701EBP+TG45 is designed to minimize electromagnetic interference (EMI), ensuring that it does not affect nearby electronic devices.
• Flexible Power Supply: This amplifier can operate across a wide range of power supplies, making it versatile for use in various applications.
• Small Footprint: Its compact size makes it an excellent choice for space-constrained applications such as mobile phones, tablets, and personal media players.

Applications

The MAX9701EBP+TG45 is suitable for a range of audio applications, including:

• Portable and wireless speakers
• Mobile phones and tablets
• Personal media players
• Home audio systems
• Active speaker systems

Technical Specifications

• Output Power: Capable of delivering up to 2.4W into a 4Ω load
• Supply Voltage: Operates from a 2.7V to 5.5V power supply
• Signal-to-Noise Ratio (SNR): Excellent audio quality with a high SNR
• Package: Available in a compact 20-Pin TQFN package

The MAX9701EBP+TG45 audio amplifier from Maxim Integrated offers a blend of power, performance, and size, making it a top choice for designers looking to enhance the audio experience in their next project.
