US1MF SHIKE Electronics
Same model may have multiple batches, images only for reference.

Products specifications Report Issue?

Category Discrete Semiconductor Products - Diodes - Rectifiers - Single Diodes
Mfr MDD
Series SMAF
Package Tape & Reel
Product Status Active
Technology Standard
Voltage - DC Reverse (Vr) (Max) 1000 V
Current - Average Rectified (Io) 1A
Voltage - Forward (Vf) (Max) @ If 1.7 V @ 1 A
Speed Fast Recovery =< 500ns, > 200mA (Io)
Reverse Recovery Time (trr) 75 ns
Current - Reverse Leakage @ Vr 5 µA @ 1000 V
Capacitance @ Vr, F 15pF @ 4V, 1MHz
Mounting Type Surface Mount
Package / Case DO-221AC, SMA Flat Leads
Supplier Device Package SMAF
Operating Temperature - Junction -55°C ~ 150°C
Standard Package 12,000 pcs
MSL Level 1 (Unlimited)
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8542.39.0001
Win Source Part Number 695509-US1MF
Ultra Librarian 3D Model Ultra Librarian US1MF CAD Model

Description

The 695509-US1MF is a single diode used in rectifier applications.

  • Series: SMAF
  • Category: discrete semiconductor products
  • Package: tape & reel
  • Standard Package: 12,000 pieces
  • Technology: standard
  • Maximum DC Reverse Voltage: 1000V
  • Average Rectified Current: 1A
  • Forward Voltage @ 1A: 1.7V
  • Reverse Recovery Time: 75ns
  • Reverse Leakage Current: 5μA @ the maximum reverse voltage
  • Capacitance @ 4V and 1MHz Frequency: 15pF
  • Junction Temperature Range: -55°C to 150°C
  • Mounting Type: surface mountable
  • Package/Case Type: DO-221AC, SMA Flat Leads
  • Supplier Device Package: SMAF
  • MSL Level: 1 (Unlimited)
  • REACH Status: unaffected
  • HTSUS Code: 8542.39.0001
  • Manufacturer: MDD
  • Status: currently active.
