DKA30A-15

Name: DKA30A-15
Brand: Mean Well Enterprises Co., Ltd.
SKU: 585016
Availability: InStock
Rating: 4.93 (5 reviews)

Get a Quote

Part No	DKA30A-15
Manufacturer	Mean Well Enterprises Co., Ltd.
Catalog	Power Supplies Board Mount DCDC Converters
Description	DC DC CONVERTER +/-15V 30W
Datasheet	DKA30A-15 Datasheet
Sample
Rohs State
ECAD Module
	Add to BOM List New List Existing List This product has been added to your list. List name
Need Help

Products specifications Report Issue?

Category	Power Supplies - Board Mount - DC DC Converters
Mfr	Mean Well Enterprises Co., Ltd.
Series	DKA30 (30W)
Package	Tube
Product Status	Active
Type	Isolated Module
Number of Outputs	2
Voltage - Input (Min)	9V
Voltage - Input (Max)	18V
Voltage - Output 1	15V
Voltage - Output 2	-15V
Current - Output (Max)	1A, 1A
Power (Watts)	30 W
Voltage - Isolation	1 kV
Applications	ITE (Commercial)
Features	Remote On/Off, OCP, SCP
Temperature Range - Operating	-40°C ~ 85°C (With Derating)
Efficiency	80%
Mounting Type	Through Hole
Package / Case	8-DIP Module
Size / Dimension	2.00" L x 2.00" W x 0.83" H (50.8mm x 50.8mm x 21.0mm)
Base Product Number	DKA30
Standard Package	150 pcs
MSL Level	1 (Unlimited)
REACH Status	REACH Unaffected
ECCN	EAR99
HTSUS	8504.40.9580
Win Source Part Number	585016-DKA30A-15
Ultra Librarian 3D Model	Ultra Librarian DKA30A-15 CAD Model

Alternative Products

Description

The DKA30A-15 is a 30W DC/DC converter from Mean Well Enterprises Co., Ltd.

Manufacturer: Mean Well Enterprises Co., Ltd
Product: DKA30A-15
Series: DKA30
Mounting: Board Mount
Type: Isolated Module
Features: Remote On/Off, Overcurrent Protection (OCP), Short Circuit Protection (SCP)
Voltage Isolation: 1 kV
Outputs: Two
Maximum Output Current: 1A each
Input Voltage: 9V to 18V
Output Voltages: 15V and -15V
Package Size: 2.00" L x 2.00" W x 0.83" H
Mounting Type: Through Hole
Operating Temperature: -40°C ~ 85°C (with derating)
Efficiency: 80%
Approvals: CE
Application: ITE (Commercial)
